Rear Set Fill Plate (Drift) Enduro Cell®, ED-AEF-R, 5-44 Gallons

Rear Set Fill Plate (Drift) Enduro Cell®, ED-AEF-R, 5-44 Gallons

SKU: ED-AEF-R

Fuel Safe's Rear Set Fill Plate Cell (formally Drift Cell) offers the same durability, and cost efficient standards, as a complete Enduro Cell® with the added feature of a rear set fill plate to accommodate the needs of a drift driver. By shifting the location of the cell's fill plate, access to internal fuel pumps and collectors becomes easier and quicker for drivers looking for efficiency. A cell with a rear set fill plate offers the best placement for fuel pickup when a driver accelerates, shifting fuel towards the back of the cell where collectors and internal pumps are ready to charge. Fuel Safe's complete Rear Set Fill Plate Cell houses our durable FIA-FT3 certified Enduro Cell bladder, designed for use with all hydrocarbon fuels, E85 blend, and alcohol (alcohol use requires the removal of foam baffling), in a light weight raw aluminum container with external flange. Rear Set Fill Plate cells are available in 5, 8, 12, 15, 20, 22, 25, 32, and 44 gallon capacities. For details on dimensions, capacity, and SKU codes see below for details.

Complete Rear Set Fill Plate Cells feature:
- High strength, FIA-FT3 certified Enduro Cell® bladder
- Raw Aluminum Container
- Rear Set SF4X6B-A Fill Plate
- Full safety foam baffling- minimizes fuel slosh and the potential for an explosion
- Aircraft grade nut ring and gasket
- Fuel pickup assembly (factory installed)
- 5 year manufacturer warranty

Recommended upgrades: surge tank, sending unit, and more! See the parts section, or Fuel Safe's catalog, for a complete listing of all available accessories

$730.00

*Capacity/Size

*Fill Options

*Pickup Size

*Return Size

*Vent Size (With rollover protection)

Collector/Surge Tank (Recommended Upgrade)

Sending Unit / Fuel Gauge (Recommended Upgrade)

0-90 ohm Sending Unit +$107.00
240-33 ohm Sending Unite +$107.00
10-180 ohm Sending Unit +$107.00
0-90 ohm Fuel Gauge (2" Autometer) +$83.00

Color Options (Powder Coat)

Spare Fuel Cell Gasket Kit

* Required Fields

$730.00

Qty:

| Add to Compare

| Add to Compare

Product Description

Details

Rear Set Fill Plate Enduro Cell information.

Part No.	Capacity	Description, Dimensions
ED105-AEF-R	5 Gallons	Includes Enduro Molded Bladder, Aluminum Container (RAW) w/ External Flange, Rear Set SF4X6B-A fill plate, and Foam Baffling. 13.625" L x 13.625" W x 8.375" H
ED108-AEF-R	8 Gallon	Includes Enduro Molded Bladder, Aluminum Container (RAW) w/ External Flange, Rear Set SF6X10E-A fill plate, and Foam Baffling. 20.75" L x 16.00" W x 7.75" H
ED112-AEF-R	12 Gallon	Includes Enduro Molded Bladder, Aluminum Container (RAW) w/ External Flange, Rear Set SF6X10E-A fill plate, and Foam Baffling.20.75" L x 17.875" W x 9.50" H
ED115-AEF-R	15 Gallon	Includes Enduro Molded Bladder, Aluminum Container (RAW) w/ External Flange, Rear Set SF6X10E-A fill plate, and Foam Baffling.26.000" L x 17.875" W x 9.50" H
ED122A-AEF-R	22 Gallon	Includes Enduro Molded Bladder, Aluminum Container (RAW) w/ External Flange, Rear Set SF6X10E-A fill plate, and Foam Baffling. 34.00"W x 18.00"L x 9.50"H
ED122B-AEF-R	22 Gallon	Includes Enduro Molded Bladder, Aluminum Container (RAW) w/ External Flange, Rear Set SF6X10E-A fill plate, and Foam Baffling. 25.50" L x 17.125" W x 13.75" H
ED125-AEF-R	25 Gallon	Includes Enduro Molded Bladder, Aluminum Container (RAW) w/ External Flange, Rear Set SF6X10E-A fill plate, and Foam Baffling. 26.25" L x 17.875" W x 14.50" H
ED132A-AEF-R	32 Gallon	Includes Enduro Molded Bladder, Aluminum Container (RAW) w/ External Flange, Rear Set SF6X10E-A fill plate, and Foam Baffling.34.50" L x 17.875" W x 14.625" H
ED132B-AEF-R	32 Gallon	Includes Enduro Molded Bladder, Aluminum Container (RAW) w/ External Flange, Rear Set SF6X10E-A fill plate, and Foam Baffling. 26.25" L x 17.75" W x 18.50" H
ED144-AEF-R	44 Gallon	Includes Enduro Molded Bladder, Aluminum Container (RAW) w/ External Flange, Rear Set SF6X10E-A fill plate, and Foam Baffling. 25.75" L x 25.75" W x 17.00" H
